| Capacity |
14,000 lb. |
| Lifting Height |
80″ (6′ 8″) |
| Overall Width Of Columns (Without Motor) |
130 7/8″ (10′ 10 7/8″) |
| Overall Width Of Columns (With Motor) |
138 7/8″ (11′ 6 7/8″) |
| Overall Length With Approach Ramp |
255″ (21′ 3″) |
| Length Between Columns |
197 1/4″ (16′ 5 1/4″) |
| Runway Length |
208 5/8″ (17′ 4 5/8″) |
| Runway Width |
20″ |
| Thickness Of Runway |
8 3/4″ |
| Width Between Runways |
46 7/8″ (w/ Rail 44 3/8″) |
| Outside Runway To Outside Runway |
86 7/8″ (7′ 2 7/8″) |
| Clearance Under Runways |
71 1/4″ (5′ 11 1/4″) |
| Clearance Between Columns |
116″ (9′ 8″) |
| Height Of Columns |
91 1/8″ (7′ 7 1/8″) |
| Maximum Wheel Base |
197″ (16′ 5″) |
| Drive Thru |
102 1/8″ (8′ 6 1/8″) |
| Air Requirement |
85-115 PSI (EXTERNAL AIR SUPPLY REQUIRED) |
| Motor/Electrical Requirement |
220 volt single (1) phase.A 30 amp breaker is recommended |
| Oil Requirement |
3-5 GallonsAW32/AW46 (NOT INCLUDED) |
